Allow Lists

An allow list is a reusable access-control policy that you attach to a proxy host to restrict who can reach the protected upstream application.

​
How Allow Lists Work

  1. You create the allow list once in the admin UI
  2. You attach it to a proxy host in that host’s configuration
  3. Aegis evaluates the allow list before proxying the request upstream
  4. If the client or user does not satisfy the allow list, access is denied before the upstream application is reached
Where to apply: Admin UI -> Hosts -> edit a proxy host -> Access List

​
Allow List Types

TypeDescription
IP / CIDRRestrict by source IP address or CIDR range
Local Username / PasswordBasic auth-style protection with local credentials
OAuth / OIDC SSOSingle sign-on via Azure AD, AWS Cognito, GitHub
Active Directory (LDAP)LDAP bind authentication against AD

​
IP / CIDR

Use IP-based allow lists to permit specific addresses or ranges:
  • Office IP ranges
  • VPN egress IPs
  • Internal networks
  • Specific trusted addresses
If the client IP matches a configured entry, the request is allowed. Otherwise, the request is denied. The same allow list can be reused across multiple hosts.

​
Local Username / Password

Protect a host with a local auth group, similar to basic auth in Nginx.
  • Define one or more usernames in the allow list
  • Aegis stores their passwords securely
  • Visitors are prompted for username and password
  • After successful authentication, an auth cookie is set so re-prompting is not immediate
Useful for staging sites, internal dashboards, and temporary hostname protection.

​
OAuth / OIDC SSO

Aegis supports host-level OAuth/OIDC access lists. These run on the protected host itself, not on the admin UI. The redirect URI always points at the protected application hostname:
https://<protected-host>/_aegis/oauth/callback
The callback path /_aegis/oauth/callback is reserved by Aegis. A successful login sets an auth cookie on the protected host.

​
Azure AD / Microsoft Entra ID

App registration setup for a protected host app.example.com:
  1. Open Microsoft Entra ID -> App registrations -> New registration
  2. Name the app (e.g., Aegis - app.example.com)
  3. Choose the supported account type
  4. Under Redirect URI, choose platform Web
  5. Set the redirect URI to https://app.example.com/_aegis/oauth/callback
  6. Create the app registration
  7. Copy the Application (client) ID
  8. Choose a tenant identifier (single-tenant: Directory ID; multi-tenant: common, organizations, or consumers)
  9. Create a client secret under Certificates & secrets
  10. For user/group picker support, add Microsoft Graph application permissions: User.Read.All, Group.Read.All and grant admin consent
In Aegis, configure:
  • Provider: Azure AD (OIDC)
  • Client ID: the Azure Application (client) ID
  • Client Secret: the client secret value
  • Issuer URL: https://login.microsoftonline.com/<tenant-id>/v2.0
Azure-specific behavior:
  • Aegis queries Microsoft Graph to populate searchable user and group pickers
  • Users are stored by UPN/email
  • Groups are stored by Graph group ID and matched during login

​
AWS Cognito

  • Provider: AWS Cognito (OIDC)
  • Client ID: Cognito app client ID
  • Client Secret: Cognito app client secret
  • Issuer URL: https://cognito-idp.<region>.amazonaws.com/<user-pool-id>

​
GitHub

  • Provider: GitHub OAuth
  • Client ID: GitHub OAuth app client ID
  • Client Secret: GitHub OAuth app client secret
GitHub access can be restricted by:
  • Allowed Usernames
  • Allowed Emails
  • Allowed Email Domains
  • Allowed GitHub Organizations

​
Active Directory (LDAP)

Host-level Active Directory access lists using LDAP bind and directory search.

​
Configuration

SettingDescription
DomainAD DNS domain (e.g., corp.example.com)
Domain ControllerHostname or IP with port (e.g., dc01.corp.example.com:389)
Bind UsernameService account with directory read access
Bind PasswordService account password
Allowed UsersPermitted user list
Allowed GroupsPermitted group list
Pass ThroughForward authenticated identity headers upstream (optional)

​
Runtime Behavior

  1. End user is prompted for username and password via HTTP Basic Auth
  2. Aegis binds to LDAP with the service account
  3. Finds the user object and resolves the UPN
  4. Attempts LDAP authentication with the end user’s supplied password
  5. Access is allowed only if the user bind succeeds and the user is in the allowed list

​
Notes

  • Plain LDAP: port 389
  • LDAPS: port 636
  • The bind account needs directory read access only; domain admin is not required
  • Aegis can test the LDAP connection and load searchable user/group pickers after AD connection details are provided
