Bulwark — Active Directory Health Check Engine
Bulwark is a standalone Active Directory health check and compliance auditing engine written in Go. It collects data from AD environments via LDAP and ADWS, evaluates over 100 built-in security rules, scores the domain on a 0–100 scale, and exports findings as JSON, XML, YAML, or interactive HTML reports.
Bulwark ships as a single binary with both a TUI (terminal UI) and a full CLI. No installation, no database, no dependencies — just point it at a domain controller and run.
What Bulwark Does
| Capability | Description |
|---|
| Health Check | Comprehensive AD security assessment with 100+ built-in rules |
| Scoring | Global health score (0–100) with category sub-scores |
| Maturity Level | Maturity rating derived from the global score |
| Supplemental Rules | User-defined rules in YAML, JSON, or XML with LDAP fallback queries |
| Multi-Protocol | LDAP, LDAPS, StartTLS, and ADWS scanning |
| Export | JSON, XML, YAML, HTML, or all formats simultaneously |
| TUI | Interactive terminal UI for guided operation |
| CLI | Full command-line interface for automation and scripting |
| Entra ID | Azure AD / Microsoft Entra ID tenant assessment |
| Cartography | AD object relationship mapping |
| Visualization | AD trust and topology visualization |
Quick Start
CLI
# Basic health check
bulwark healthcheck -u admin@corp.example.com -p 'P@ssw0rd' -d corp.example.com -t dc01.corp.example.com
# Export as HTML report
bulwark healthcheck -u admin@corp.example.com -p 'P@ssw0rd' -d corp.example.com -t dc01.corp.example.com --export html
# Export all formats
bulwark healthcheck -u admin@corp.example.com -p 'P@ssw0rd' -d corp.example.com -t dc01.corp.example.com --export all
# With supplemental rules
bulwark healthcheck -u admin@corp.example.com -p 'P@ssw0rd' -d corp.example.com -t dc01.corp.example.com --rules /path/to/rules/
# TLS options
bulwark healthcheck -u admin@corp.example.com -p 'P@ssw0rd' -d corp.example.com -t dc01.corp.example.com --ldaps
bulwark healthcheck -u admin@corp.example.com -p 'P@ssw0rd' -d corp.example.com -t dc01.corp.example.com --starttls
TUI
# Launch interactive terminal UI
bulwark
Scan Modes
| Mode | Command | Description |
|---|
| Health Check | healthcheck | Full AD security assessment with rule evaluation and scoring |
| Scanner | scanner | Data collection only (no rule evaluation) |
| Cartographer | carto | AD object relationship mapping |
| Visualizer | visualize | Trust and topology visualization |
| Exporter | export | Re-export previously collected data in different formats |
| Entra ID | entraid | Azure AD / Microsoft Entra ID tenant assessment |
Scoring
Bulwark calculates a global health score (0–100) from four weighted category scores:
| Category | Description |
|---|
| Stale Objects | Inactive accounts, expired passwords, legacy encryption, functional level |
| Privileged Accounts | Admin group hygiene, service accounts in admin groups, delegation risks |
| Trust Relationships | Cross-domain trusts, SID filtering, trust configuration |
| Anomalies | Misconfigurations, missing security features, exposed services |
Maturity Level
The maturity level is derived from the global score and indicates the overall AD security posture.
Authentication
| Option | Description |
|---|
-u / --user | Username in UPN format (user@domain.com) |
-p / --password | Password |
-d / --domain | Domain FQDN |
-t / --target | Domain controller IP or hostname |
TLS Options
| Flag | Description |
|---|
--ldaps | Use LDAPS (port 636) |
--starttls | Use StartTLS on standard LDAP (port 389) |
--insecure | Skip TLS certificate verification |
Protocol Selection
| Mode | Behavior |
|---|
| LDAP then ADWS (default) | Try LDAP first, fall back to ADWS if it fails |
| ADWS then LDAP | Try ADWS first, fall back to LDAP |
| LDAP only | Only use LDAP |
| ADWS only | Only use ADWS |
| Format | Flag | Description |
|---|
| JSON | --export json | Machine-readable JSON with all collected data and findings |
| XML | --export xml | XML export |
| YAML | --export yaml | YAML export |
| HTML | --export html | Interactive HTML report with charts, tables, and drill-down |
| All | --export all | Export to every format simultaneously |
./bulwark.out/ by default, or a custom path via --output.
Data Collection
Bulwark collects comprehensive AD state data including:
| Category | Data Points |
|---|
| Domain | FQDN, NetBIOS, SID, creation date, functional levels, schema version |
| Users | Total, enabled, disabled, active, inactive, locked, password flags (never expires, not required, reversible encryption, DES, no pre-auth), SID history, delegation, LAPS |
| Computers | Same metrics as users, plus OS distribution and LAPS coverage |
| Groups | Privileged group membership, service accounts, nested membership |
| Trusts | Trust relationships, types, SID filtering, transitivity |
| Domain Controllers | FSMO roles, OS versions, reachability, SMB/Kerberos settings |
| GPOs | Audit policies, LSA settings, WSUS, Defender ASR, screen saver, firewall rules, hardened paths |
| PKI | Certificate authorities, templates, enrollment services, trusted certificates |
| Exchange | Install date, schema version, privilege escalation risks |
| DNS | AD-integrated DNS zones |
| Azure AD | SSO account, AD Connect, tenant info, Kerberos trust |
| Password Distribution | Age distribution histograms for passwords and LAPS |
| Control Paths | ACL-based attack paths and dangerous permissions |
| Delegation | Unconstrained, constrained, and protocol transition delegation |
