Bulwark — Active Directory Health Check Engine

Bulwark is a standalone Active Directory health check and compliance auditing engine written in Go. It collects data from AD environments via LDAP and ADWS, evaluates over 100 built-in security rules, scores the domain on a 0–100 scale, and exports findings as JSON, XML, YAML, or interactive HTML reports. Bulwark ships as a single binary with both a TUI (terminal UI) and a full CLI. No installation, no database, no dependencies — just point it at a domain controller and run.

What Bulwark Does

Capability	Description
Health Check	Comprehensive AD security assessment with 100+ built-in rules
Scoring	Global health score (0–100) with category sub-scores
Maturity Level	Maturity rating derived from the global score
Supplemental Rules	User-defined rules in YAML, JSON, or XML with LDAP fallback queries
Multi-Protocol	LDAP, LDAPS, StartTLS, and ADWS scanning
Export	JSON, XML, YAML, HTML, or all formats simultaneously
TUI	Interactive terminal UI for guided operation
CLI	Full command-line interface for automation and scripting
Entra ID	Azure AD / Microsoft Entra ID tenant assessment
Cartography	AD object relationship mapping
Visualization	AD trust and topology visualization

Quick Start

CLI

# Basic health check
bulwark healthcheck -u admin@corp.example.com -p 'P@ssw0rd' -d corp.example.com -t dc01.corp.example.com

# Export as HTML report
bulwark healthcheck -u admin@corp.example.com -p 'P@ssw0rd' -d corp.example.com -t dc01.corp.example.com --export html

# Export all formats
bulwark healthcheck -u admin@corp.example.com -p 'P@ssw0rd' -d corp.example.com -t dc01.corp.example.com --export all

# With supplemental rules
bulwark healthcheck -u admin@corp.example.com -p 'P@ssw0rd' -d corp.example.com -t dc01.corp.example.com --rules /path/to/rules/

# TLS options
bulwark healthcheck -u admin@corp.example.com -p 'P@ssw0rd' -d corp.example.com -t dc01.corp.example.com --ldaps
bulwark healthcheck -u admin@corp.example.com -p 'P@ssw0rd' -d corp.example.com -t dc01.corp.example.com --starttls

TUI

# Launch interactive terminal UI
bulwark

The TUI provides guided menus for configuration, scan execution, rule management, and result viewing.

Scan Modes

Mode	Command	Description
Health Check	`healthcheck`	Full AD security assessment with rule evaluation and scoring
Scanner	`scanner`	Data collection only (no rule evaluation)
Cartographer	`carto`	AD object relationship mapping
Visualizer	`visualize`	Trust and topology visualization
Exporter	`export`	Re-export previously collected data in different formats
Entra ID	`entraid`	Azure AD / Microsoft Entra ID tenant assessment

Scoring

Bulwark calculates a global health score (0–100) from four weighted category scores:

Category	Description
Stale Objects	Inactive accounts, expired passwords, legacy encryption, functional level
Privileged Accounts	Admin group hygiene, service accounts in admin groups, delegation risks
Trust Relationships	Cross-domain trusts, SID filtering, trust configuration
Anomalies	Misconfigurations, missing security features, exposed services

Maturity Level

The maturity level is derived from the global score and indicates the overall AD security posture.

Authentication

Option	Description
`-u` / `--user`	Username in UPN format (`user@domain.com`)
`-p` / `--password`	Password
`-d` / `--domain`	Domain FQDN
`-t` / `--target`	Domain controller IP or hostname

TLS Options

Flag	Description
`--ldaps`	Use LDAPS (port 636)
`--starttls`	Use StartTLS on standard LDAP (port 389)
`--insecure`	Skip TLS certificate verification

Protocol Selection

Mode	Behavior
LDAP then ADWS (default)	Try LDAP first, fall back to ADWS if it fails
ADWS then LDAP	Try ADWS first, fall back to LDAP
LDAP only	Only use LDAP
ADWS only	Only use ADWS

Export Formats

Format	Flag	Description
JSON	`--export json`	Machine-readable JSON with all collected data and findings
XML	`--export xml`	XML export
YAML	`--export yaml`	YAML export
HTML	`--export html`	Interactive HTML report with charts, tables, and drill-down
All	`--export all`	Export to every format simultaneously

Output is written to ./bulwark.out/ by default, or a custom path via --output.

Data Collection

Bulwark collects comprehensive AD state data including:

Category	Data Points
Domain	FQDN, NetBIOS, SID, creation date, functional levels, schema version
Users	Total, enabled, disabled, active, inactive, locked, password flags (never expires, not required, reversible encryption, DES, no pre-auth), SID history, delegation, LAPS
Computers	Same metrics as users, plus OS distribution and LAPS coverage
Groups	Privileged group membership, service accounts, nested membership
Trusts	Trust relationships, types, SID filtering, transitivity
Domain Controllers	FSMO roles, OS versions, reachability, SMB/Kerberos settings
GPOs	Audit policies, LSA settings, WSUS, Defender ASR, screen saver, firewall rules, hardened paths
PKI	Certificate authorities, templates, enrollment services, trusted certificates
Exchange	Install date, schema version, privilege escalation risks
DNS	AD-integrated DNS zones
Azure AD	SSO account, AD Connect, tenant info, Kerberos trust
Password Distribution	Age distribution histograms for passwords and LAPS
Control Paths	ACL-based attack paths and dangerous permissions
Delegation	Unconstrained, constrained, and protocol transition delegation
